Frame
Scalpel, lightweight carbon construction, 120mm travel, Proportional Response Suspension and Geometry, FlexPivot Chainstay, full internal cable routing, 73mm BSA, 1.5" headtube with 1-1/8" upper reducer/internal cable guide, 148x12mm thru axle, 55mm chainline, UDH, post-mount disc – 160mm native
-
Fork
Lefty Ocho 120 Carbon, 120mm, Chamber Damper, OppO Spring System, tapered steerer, 50mm offset, TwistLoc Ultimate remote dual lockout
-
Headset
Acros ICR
-
Rear Shock
RockShox SIDLuxe Select+, 2-Pos mode adjust, adjustable rebound, 190x45, TwistLoc Ultimate remote dual lockout
-
Rear Derailleur
SRAM XO Eagle AXS, T-Type
-
Shifters
SRAM AXS T-Type Pod Controller
-
Chain
SRAM XO, T-Type, 12-speed
-
Crank
SRAM XO, T-Type, 34T
-
Rear Cogs
SRAM XO Eagle, 10-52, T-Type, 12-speed
-
Bottom Bracket
SRAM DUB BSA 73mm MTB Wide
-
Brakes
SRAM Level Silver Stealth, 4-piston hydraulic disc, SRAM HS2 180/160mm rotors
-
Brake Levers
SRAM Level Silver Stealth
-
Rims
DT Swiss XRC 1501 SPLINE ONE, carbon, 30mm inner width, hookless, TSS tubeless ready
-
Spokes
DT Competition Race, straight pull
-
Tire Size
2.4
-
Wheel Size
29
-
Hubs
DT Swiss Lefty, 6-bolt (F) / 240 Ratchet EXP 36, 6-bolt, XD driver (R)
-
Tires
(F) Maxxis Rekon Race WT, 29x2.4", EXO Protection, tubeless ready / (R) Maxxis Aspen WT, 29x2.4", EXO Protection, tubeless ready
-
Handlebar
SystemBar XC-One Flat, carbon, integrated bar/stem, internal cable routing, 5° upsweep, 8° backsweep, 760mm width, -6° stem, 1-1/8" clamp
-
Stem
SystemBar XC-One Flat, carbon integrated bar/stem
-
Grips
RockShox Smooth Silicone
-
Saddle
Prologo Dimension NDR, Tirox rails
-
Seatpost
Fox Transfer SL Performance Elite, 31.6, 125mm (S), 150mm (M-XL)
-
Wheel Sensor
Cannondale Wheel Sensor
